Product Description
HOT PLATEN CORE VENEER DRYER also called Breathing Veneer Dryer Machine, it is one of three types core veneer dryer.
Specification of Breathing Veneer Dryer Machine
|
Models
|
SEHVD48/15
|
SEHVD58/15
|
|
Max. Working Pressure
|
126T
|
140T
|
|
Working Layers
|
15
|
15
|
|
Distance Between Each Layer
|
70mm
|
70mm
|
|
Hot Platen Size
|
1370*2700*42mm, 2 in 2 out
|
1700*2700*42mm, 2 in 2 out
|
|
Groove
|
Diamond groove, Diamond spacing 40*40mm, depth:1mm, width:1.5mm
|
Diamond groove, Diamond spacing 40*40mm, depth:1mm, width:1.5mm
|
|
Hot Platen Quantity
|
16pcs
|
16pcs
|
|
Cylinder
|
100mm*1050mm*4pcs
|
120mm*1050mm*4pcs
|
|
Motor Power
|
18.5KW
|
18.5KW
|
|
Hydraulic Station
|
Sclient power pack
|
Sclient power pack
|
|
Control System
|
PLC automatic control
|
PLC automatic control
|
|
Up, Middle, Bottom Beam Height
|
400mm, 260mm, 400mm
|
500mm, 300mm, 500mm
|
|
Column Width
|
300mm
|
350mm
|
|
Machine Weight
|
26.8T
|
37T
|
Machine Features:
1. It is suitable high quality core veneer dryer, especially for thick core veneer.
2. It works same as hot press machine, the hot platen will press core veneer to make it more flat.
3. Normally one 4ft veneer peeling line need equip with 2-3 sets 15 layers solid press dryer.
4. It is widely used in Russia, Indonesia area for Birch and Albizia core veneer, etc.
5. There is grooves on hot platen surface for veneer moisture remove.
Detail Pictures
Machine Advantage
- CNC Platner Processing Frame
Whole frame is made of GB Q235 steel plate or manganese steel, through CNC planer processing.
500T hot press adopts 35mm steel.
600T hot press adopts 40mm steel.
- Full Auto PLC Control Sytem
Adopts Taiwan DELTA PLC + Touch Screen,
France Schneider Electrical Parts,
Automatic high voltage 6 section voltage holding time control system
- Wuxi Original Cylinder
Wuxi Suyi Brand Oil Cylinder,
Condensing cast iron,
Chrome plating surface,
Weight improved oil cylinder,
No oil leaking problem.
- Grooved Hot Platen
Hot platen is 42mm thickness, thermal oil double in and out.
Groove depth 1mm, width 1.5mm,
CNC planer process and polishing,
Uniform heat transfer,
Small surface temperature difference
-
5. Silent Dust-free Hydraulic StationAdopts Taiwan HEANG valve,Kinyuen vane pump,
Siemens motor.
Slient, Dust-free, Maintenance-free.
- Synchronous Closer
Guarantee each layer close at same time, so that each layer veneer can have same moisture content.
