Short Cycle Hot Press Machine

$17,000.00

Short cycle melamine laminating hot press machine is widely used in wood processing, building materials and decoration…etc.
It is suitable for the veneered processing of particle board, OSB, MDF, HDF and melamine impregnated paper and high density
laminated flooring ACP wear-resisting paper.

Product Description of Short Cycle Hot Press Machine

1400T short-cycle melamine laminated  hot press machine

Short Cycle Hot Press Machine

Short Cycle Hot Press Machine

Short Cycle Hot Press Machine

Short Cycle Hot Press Machine

Short Cycle Hot Press Machine

















































































Short cycle melamine laminating hot press machine is widely used in wood processing, building materials and decoration…etc.
It is suitable for the veneered processing of particle board, OSB, MDF, HDF and melamine impregnated paper and high density
laminated flooring ACP wear-resisting paper. Variety specifications include 4*8′, 4*9′, 5*8′, 5*9′, 6*8′, 6*9′, 7*8′, 7*9′, 6*12…etc.
Variety models include 1200T, 1400T, 1600T, 1800T, 2000T, 2400T, 2800T, 3200T series lamination hot pressing machine.

Short Cycle Hot Press Machine

Specification

model TLY114×8/20-ll
nominal gross pressure 20000Kn.
direction of feeding plate HORIZONTAL
layer counting 1 layer
distance between hot platens 200mm
numbers of hot platens 2pcs
dimension of hot platens 2600×1400×180mm(up) ;2600×1400×160mm(down)
numbers of cylinder 8pcs
diameter of cylinder Φ360mm
stroke of cylinder 200mm
pressurization ≤25Mpa
the position of cylinder up
empty closing time about 2-3s
max temperature  <210
numbers of lift cylinder 4pcs
diameter of cylinder Φ80mm,Φ30
stroke of cylinder 200mm
high pressure pump flowing about89L/min
allowed pressure ≤25Mpa
power 37kw
pressure of unit plate blank 55kgf/cm²
control method automatic pump station
frame steel plate thickness 100mm
total weight 55000kgs





































Our factory produces hydraulic hot press machine that is widely used in wood processing, building decoration and other
industries.Hot press is applicable to the facing process of particle board, medium density fiberboard(MDF), melamine
impregnated paper.Through many years’s reseaches and experiments ,new-generation of press machine was devepoled
and manufactured ,with production of high speed veneer of good quality ,stable performance ,smooth and simple operation,
electromechanical integration.

Company Information

Sinoeuro Machinery is a leading brand for wood based panels machinery. Sinoeuro Machinery manufacturer is a
professional manufacturer with 26 years experience for veneer peeling, plywood machinery solutions plant with
factory layout design and processing technology support

Why choose us

1.Seller will send 1-2 technicians to guide the equipment installation and trial run.
2.The installation duration is about 10 days.
3.Buyer should pay the service fee ,each day per person for seller’s technicians in the first 10 days. Buyer should
pay the round trip ticket and board & lodging for seller’s technicians in buyer’s country.
4.The necessary conditions such as workshop, illumination and ventilation etc.
5.The construction of machine’s foundation support steel blocks.
6.The boiler and pipes & valves connected to the inlets/outlets of machine.
7.Hydraulic oil, thermal oil and fuel for boiler.
8.The necessary device, facilities and skilled worker for the installation and trial run.
9.Electric power, connected to main electric cabinet;

free sample wood panels melamine laminate hot press machine/ short cycle laminate heat press machine

Our Services

 free sample wood panels melamine laminate hot press machine/ short cycle laminate heat press machinefree sample wood panels melamine laminate hot press machine/ short cycle laminate heat press machine

FAQ

1. All kinds of mold can be made by customer’s requirements
2. All price are based on FOB, QINGDAO, China
3. Payment: by T/T 30% down payment, 70% upon machinery completion.
4. Delivery: After finishing all the payment
5. All the parameters above just for reference, for they are updating all the time
6. Package: Standard packing
7. Warranty: All the machine enjoys one year’s warranty, in this period.
Any problems of machine, please feel free to contact us. We will try our best to make it
