Spindleless Wood Clipper Machine

$9,000.00$19,900.00

Special structure to adjust the blade gap, our machine adopt double roller moving method,during peeling the blade
gap will change automaticlly according to the log diameter.
The screw part is fully close, dust and veneer chips will not enter the screw.

Product Description

spindleless wood clipper machine
spindleless wood clipper machine
Peeling hardwood and softwood with different thickness,such as Birch,Beech,Albasia,Poplar,ect.
Thickness is 1.7mm
Scars part peeling is very smooth

Specification of Spindleless Wood Clipper Machine

Model
48m/min normal type speed fix
55m/min heavy duty speed fix
40-80m/min heavy duty speed adjustable
Peel length
1300mm
1300mm
Opening
500mm
500mm
Remain logs diameter
32mm
24mm
24mm
Peel thickness
1.0-2.8mm
0.5-5.0mm
0.5-5.0mm
Cutting length
660-1300mm
500-2600mm
500-2600mm
Peel speed
48m/min
55m/min
40-80m/min
Single roller power
7.5kw
5.5kw×2pcs
7.5kw×2pcs
Double roller power
7.5kw
5.5kw×2pcs
7.5kw×2pcs
Feeding power
5.5kw
7.5kw or 11kw(Servo motor)
7.5kw or 11kw(Servo motor)
Total power
23.8kw
33.2kw
42.6kw
Roller diameter
125mm
125mm
Long-range control
None
Have
Have
Voltage
380-515v
380-515v
Bottom structure
160*65*3mm(Channel)
8mm(Steel)
8mm(Steel)
Total weight
4000kg
6000kg
6700kg
Overall dimension
4300*2500*1200mm
4200*2500*1200mm
4800*2500*1500mm

Spindleless Wood Clipper Machine Detailed Images

  1. Key Technology
    Special structure to adjust the blade gap, our machine adopt double roller moving method,during peeling the blade
    gap will change automaticlly according to the log diameter.
    The screw part is fully close, dust and veneer chips will not enter the screw.spindleless wood clipper machine
  2. Servo Motor

    The feeding motor is 11kw famous brand servo motor.It can guarantee machine working stable and precise.The
    thickness of the veneer is accurate. The cutting motor is 3.7kw servo motor,have enough power to cut the thick
    veneer,keep smooth cutting edges and precise size.
    spindleless wood clipper machine

  3. Guide Rail
    The guide rail part make by high temperature quenching and CNC cutting method,increases the hardness and ensure
    guide rail has unlimited service life.
    Avoid the wear problem like ordinary screw, and ensure machine operation no
    deviation, veneer width and thickness are accurate,produce high quality veneer.
    spindleless wood clipper machine

  4. Electroplating Roller

    All peeling rollers have been quenched and electroplating,increases the peeling roller hardness and sevice life.
    The roller pattern have different type.We will choose the right roller pattern acoording to clients differen wood species.
    spindleless wood clipper machine

  5. Schneider Electric
    Our electric is international famous brand Schneider or Siemens. Easy to get at anywhere.
    spindleless wood clipper machine

Packaging & Shipping

Company Introduction

Sinoeuro Machinery is a manufacturer of wood-based panels with wel-equipped testing facilities and strongtechnical force.
We are committed to providing customers a complete solution for veneer peeling line, plywoodproduction line, sawmill
production line, LVL, block board production line etc. All electronic parts are worldamous brand, like Delta, Schneider, Siemens etc.

Related Products

Clients feedback

FAQ

1. Can you customize products for clients?
Yes, We can customize and produce woodworking machines according to the customer’s requirements or drawings.
2. How can we trust your factory?
We sincerely invite you come to our factory to verify the real situation of our machine, and know more about our
factory.
3. What about the paymet and delivery?

Payment: by T/T 30% down payment, 70% upon machinery completion.
Delivery: After finishing all the payment
Package: Standard packing or as clients’ requirement
4.What’s your machine warranty?
Warranty: All the machine enjoys one year’s warranty, in this period.
Any problems of machine, please feel free to contact us. We will try our best to make it.All kinds of mold can be made by customer’s requirements
5.Do you supply any formula to buyer?
yes, we supply formulas to buyer.
